Moldagem por extrusão de moldagem por injeção antibacteriana de grau alimentício POM polioximetileno M90

Taxa de fluxo de fusão: 9g/10min

Densidade: 1,41g/cm³

Embalagem: 25KG/saco

send contact

POM M90 é um material de polioximetileno (POM) de alto desempenho projetado para uma variedade de aplicações, incluindo aquelas que exigem conformidade com padrões de contato com alimentos, alta resistência ao desgaste e componentes automotivos. Este grau de POM atende a rigorosos padrões de segurança, durabilidade e desempenho para uso em ambientes exigentes.
Característica principal
Grau de contato com alimentos: Certificado para uso em aplicações de contato com alimentos, garantindo conformidade com regulamentos e padrões de segurança.
Alta resistência ao desgaste: Com resistência superior ao desgaste, é ideal para peças de alto atrito e usadas com frequência.
Aplicações automotivas: Adequado para peças automotivas, como capôs, componentes eletrônicos, componentes externos, rodas e engrenagens.
Produtos de Parede Fina: Otimizados para a produção de peças de parede fina com excelentes características de fluidez e estabilidade dimensional.

IMPORTANT NOTICE FOR USE IN PROCESSING:

1, product storage products to maintain the integrity of the package stored in room temperature, dry indoor warehouse, and should not be subjected to direct sunlight; the product has no expiry date, it is recommended that the use of 2 years, after opening the package should be used immediately.
2, the use of the requirements of the product should be fully dry before use, it is recommended to use 180 ~ 160 ℃ hot air drying 4-6 hours, dew point ≤ -40 ℃, melting temperature of 280-300 ℃.

Key Attributes

YUNTIANHUA® POM M90
Product information
Manufacturer		YunNan YunTianHua Co., Ltd
Certificates		MSDS
Part Marking Code		>POM<
Material Shape		Pellets
Process		Injection molding Extrusion molding
Polymer		Copolymer
FR		HB
Material Attribute		Food Contact grade Wear resistant grade
specification		EN 71/3 FDA RoHS UL
Features		Dimensional stability High flow Fatigue resistance High hardness High stiffness Low friction Low warpage Good electrical properties Acid resistant Alkali-resisting Chemical Resistant Solvent Resistant Lower die deposit Antibiosis
Application		Auto engine cover Automotive electronics Automotive exterior parts Wheels Fittings Gears Valves/valve parts Thin wall products
UL File NO.		E497744
Physical property	Standard	Value	Unit
Density	ISO 1183	1.41	g/cm³
Water Absorption 23°C 24hr	ISO 62	0.6	%
Melt Index 190°C 2.16kg	ISO 1133	9	g/10min
Mechanical behavior	Standard	Value	Unit
Tensile Modulus	ISO 527	2600	MPa
Tensile Strength Yield	ISO 527	60	MPa
Elongation Break	ISO 527	35	%
Flexural Strength	ISO 178	88	MPa
Flexural Modulus	ISO 178	2500	MPa
Charpy Notch Impact 1eA	ISO 179	6	kJ/m²
Thermal	Standard	Value	Unit
HDT Unannealed 1.8MPa	ISO 75	95	°C
Flammability	Standard	Value	Unit
Flame Rating All Color 0.75mm	UL94	HB
Flame Rating All Color 3.0mm	UL94	HB
UL	Standard	Value	Unit
UL FlameRating ALL 0.75mm	UL94	HB
UL FlameRating ALL 3.0mm	UL94	HB
RTI Elec ALL 0.75mm	UL 746B	50	°C
RTI Elec ALL 3.0mm	UL 746B	50	°C
RTI Imp ALL 0.75mm	UL 746B	50	°C
RTI Imp ALL 3.0mm	UL 746B	50	°C
RTI Str ALL 0.75mm	UL 746B	50	°C
RTI Str ALL 3.0mm	UL 746B	50	°C
Injection molding		Value	Unit
Dry Temperature		80~90	°C
Dry Time		3~4	hr
Zone1 Temperature		160~180	°C
Zone2 Temperature		170~200	°C
Zone3 Temperature		190~210	°C
Nozzle Temperature		180~210	°C
Melt Temperature		180~210	°C
Mould Temperature		60~90	°C
Injection Pressure		50~100	MPa
Screw Speed		50~120	rpm
Back Pressure		0.5	MPa
Holding Pressure		30~80	MPa
Extrusion molding		Value	Unit
Melt Temperature		180~190	°C
