dupont delrin 100st ultra impact resistant pom material

DuPont Delrin 100ST NC010 | Ultra impact resistant

Application: Profiles / Sheet

Viscosity: High

Packing: 25KG/Bag
Get Quotation

 Dupont Delrin 100ST NC010 POM pellets Description

Application

Delrin 100ST is an ultra high impact homopolymer polyoxymethylene (POM-H) produced by Dupont Performance Polymer. It is suitable for injection molding and extrusion molding, has a melt index of 2g/10min at 190°C and 2.16kg. It has high viscosity, ultra high hardness and ultra high impact resistance, and is commonly used in profile and sheet manufacturing.
delrin 500p white pom pellet

⚠️Note: DuPont Delrin 100ST NC010 is milky white pom, as shown in the left picture. If you need black acetal pellets, the grade is Delrin 100ST BK602, please contact us.

DuPont Delrin 100ST NC010 POM pellets Advantage

  • Ultra high impact resistant polyoxymethylene material. Compared to conventional acetal materials, Delrin 100ST POM has higher impact resistance. Under a 23°C test environment, the cantilever beam notched impact reaches 90kJ/㎡, and the simply supported beam notched impact reaches 90kJ/㎡, which is much higher than conventional POM materials. It is suitable for applications with high impact resistance requirements.
  • Delrin 100ST POM has excellent wear resistance. Its specific wear rate vs. itself is 0.0006 mm³/N.m, and its dynamic coefficient of friction vs. itself is only 0.32 per hour, which is lower than that of 100P and 500P POM materials. It is suitable for the production of products with high lubricity requirements.

Why choose Baiyou as DuPont Delrin 100ST NC010 POM pellets  supplier?

  • Leading acetal pellets supplier (POM), 20+ years of experience of plasticizing materials factory
  • Fastest Arrival, with warehouses in multiple ports
  • 1,000+ types of resins products are available, and we have cooperated with large petrochemical groups for 30+ years
  • Free Samples for production testing
  • Wholesale price, even a piece of goods is based on the wholesale price
 Key Attributes
DuPont Delrin 100ST NC010
Product information
ManufacturerDuPont Performance Polymers
Part Marking Code>POM material<
ColorNC
Material ShapePOM Pellets
Process
Injection molding POM material
Extrusion molding POM material
Polymer Homopolymer Polyacetal (POM-H)
ViscosityHigh viscosity
FR HB
Material AttributeSuper high impact
specificationUL
Features
·High toughness ·Super high impact
ApplicationsProfiles Sheet
Addictives·Lubricant ·Mold Releases
UL File NO. E41938
Physical propertiesStandardValueUnit
DensityISO 11831340kg/m³
Shrinkage FlowISO 294 0.8%
Shrinkage xFlowISO 294 1.1%
Water Absorption 2.00mmISO 62 0.9%
Humidity Absorption 2.00mmISO 62 0.35%
Melt Index 190°C 2.16kgISO 1133 1.7cm³/10min
Melt Index 190°C 2.16kgISO 1133 2g/10min
Melt Density INTERNAL METHOD 1140kg/m³
Hardness Standard Value Unit
Rockwell Hardness M(Scale) ISO 2039 57
Rockwell Hardness R(Scale)ISO 2039 105
Mechanical behaviorStandardValueUnit
Tensile ModulusISO 5271400MPa
Tensile Strength YieldISO 52741MPa
Elongation Yield ISO 52730%
Elongation Break ISO 52750%
Poisson Ratio INTERNAL METHOD 0.43
Tensile Creep Modulus 1hrISO 899 1100MPa
Tensile Creep Modulus 1000hrISO 899 550MPa
Flexural Strength 3.5%StrainISO 178 34MPa
Flexural Modulus ISO 178 1100MPa
Izod Notch Impact 23°C Type A ISO 180 90kJ/m²
Izod Notch Impact -30°C Type AISO 180 20kJ/m²
Charpy Notch Impact 23°C 1eA ISO 179 90kJ/m²
Charpy Notch Impact -30°C 1eAISO 179 18kJ/m²
Charpy Un-notch Impact 23°C ISO 179 NBkJ/m²
Charpy Un-notch Impact -30°CISO 179 NBkJ/m²
Friction coefficient dynamic VS itself 1hr  ASTM D18940.32
Specific wear rate VS itselfASTM D18940.00006
mm³/N.m
ThermalStandardValueUnit
HDT 1.8MPa ISO 7560°C
HDT 0.45MPa ISO 75100°C
Vicat Softening
Temperature 50°C/hr 10N 		ISO 306 170°C
Melting Temperature 10°C/min ISO 11357 178°C
Glass transition temperature 10℃/minISO 11357-35℃
CLE Flow ISO 11359 1E-4m/m/K
CLE xFlow ISO 11359 1E-4 m/m/K
Thermal diffusivityINTERNAL METHOD6E-8㎡/s
Electrical propertiesStandardValueUnit
Volume resistivityIEC 626311E+12Ω.m
Surface resistivityIEC 62631-3-21E+14Ω
Dielectric constant 100HzIEC 62631-2-14.4
Dielectirc constant 1MHzIEC 62631-2-13.8
CTI IEC 60112600V
FlammabilityStandardValueUnit
Flame Rating All Color 1.5mmUL94 HB
Flame Rating All Color 3.0mm UL94 HB
GWFI 1mm IEC 60695550°C
GWFI 2mmIEC 60695550°C
GWFI 3mmIEC 60695550°C
Burning Rate 1.00mm ISO 379541mm/min
VDA PropertiesStandardValueUnit
Emission VDA 275 8mg/kg
⚠️The technical data sheet of DuPont Derlin 100ST acetal, from Dupont performance polymers, if there are difference, please refer to the official website of Dupont.
