ABS

Chimei Polylac PA-747 ABS

Application: Safety helmet; Auto parts; Toy parts; Home appliance application

Melt flow rate: 12g/10min

Packing:25KG/Bags

Process:Injection molding ABS material
Get Quotation

 Chimei Polylac PA-747 ABS pellet Description

Polylac PA-747 is an injection molding Acrylonitrile Butadiene Styrene virgin pellets (ABS material) produced by Chi Mei Industrial Co., Ltd. Chimei PA747 ABS material has a melt index of 13ml/10min (220℃ 10kg), a medium flow rate, good impact resistance and flexibility, and is commonly used in the production of pipe fittings, helmets, toys.

Chimei Polylac PA-747 ABS Advantage

  • Excellent impact resistance. Chimei Polylac PA-747 ABS material has a cantilever notch impact of 32kJ/㎡ and a simply supported beam notch impact of 33kJ/㎡ under a 23℃ test environment. Even in an extreme low temperature environment of -30℃, it can maintain an impact resistance of more than 20kJ/㎡, making it suitable for applications requiring high impact resistance and low-temperature impact resistance.
  • Good flexibility. Compared with conventional ABS materials, Chimei PA-747 ABS has better flexibility. The bending strength under the 2.8mm/10min test standard can reach 620kg/c㎡, and the bending modulus is as high as 22000kg/c㎡. The good flexibility facilitates product manufacturing while also providing better impact resistance and bending ability for the final product.
  • Good processing performance, Polylac PA 747 ABS has a melt index of 13ml/10min under ISO 1133 test standard at 220°C and 10kg test environment. It has medium viscosity and flow rate, making it suitable for injection molding and can be used for conventional high impact resistance ABS.

Why choose Baiyou as Chimei Polylac PA-747 ABS pellets supplier?

  • Leading Acrylonitrile Butadiene Styrene raw material supplier (ABS resin),20+ years of experience in plastic product manufacturing and chemical raw material import and export
  • Fastest Arrival, with warehouses in multiple ports
  • 1,000+ types of resins are available, and we have cooperated with large petrochemical groups for 30+ years
  • Free Samples for production testing
  • Wholesale price, even a piece of goods is based on the wholesale price
 Key Attributes
Chimei  ABS  PA-747
Product information
Manufacturer
CHIMEI CORPORATION
Other Certificates
RoHS; REACH; MSDS
Part Marking Code
>ABS material<
Material Shape
ABS Pellets
Process
Injection molding ABS material
Flame retardant
HB
Material Attribute
Injection grade ABS pellets
specification
·RoHS ·UL
Features
·High toughness ABS ·High impact ABS
Application
·Automotive parts ·Toys parts ·Safety helmet ·Fridge housing ·Home Appliances Applications
·Industrial Applications ·Pipe fitting ·Rods ·Sheet ·Structural Parts ·Shoe material application
Additives
Lubricant Mold Releases
UL File NO.
E56070
Physical propertiesStandardValueUnit
Density   23°C
ASTM D792
 1.03
 g/cm³
Density   23°C
ISO 1183
 1.03
 g/cm³
Shrinkage
ISO 294
 0.4~0.7
%
Melt Index   200°C 5kg
ASTM D1238
1.1
 g/10min
Melt Index   220°C 10kg
 ISO 1133
12
cm³/10min
Hardness
Standard
Value
Unit
Rockwell Hardness   R(Scale)
ASTM D785
108

Mechanical behavior
Standard
Value
Unit
Tensile Strength   Yield 6mm/min
ASTM D638
385
 kg/cm²
Tensile Strength   Yield 50mm/min
  ISO 527
39
 Mpa
Tensile Strength   Break 50mm/min
  ISO 527
30
 MPa
Elongation   6mm/min
 ASTM D638
30
 %
Elongation   50mm/min
 ISO 527
35
 %
Flexural Strength   2.8mm/min
ASTM D790
620
 kg/cm²
Flexural Strength   2.0mm/min
ISO 178
58
 Mpa
Flexural Modulus   2.8mm/min
ASTM D790
22000
  kg/cm²
Flexural Modulus   2.0mm/min
ISO 178
1.8
 GPa
Izod Notch Impact    23°C 6.4mm
ASTM D256
32
kg-cm/cm
Izod Notch Impact    23°C 3.2mm
ASTM D256
41
kg-cm/cm
Izod Notch Impact    23°C
ISO 180
32
 kJ/m²
Izod Notch Impact    -30°C
ISO 180
23
 kJ/m²
Charpy Notch Impact   23°C
 ISO 179
33
 kJ/m²
Charpy Notch Impact   -30°C
 ISO 179
25
 kJ/m²
Thermal
Standard
Value
Unit
HDT   Annealed 1.8MPa
 ASTM D648
95
°C
HDT   Unannealed 1.8MPa
ASTM D648
85
°C
HDT   Unannealed 1.8MPa
 ISO 75
82
°C
HDT   Unannealed 1.8MPa
 ISO 75
97
°C
Vicat Softening Temperature   50°C/hr 10N
ASTM D1525
103
°C
Vicat Softening Temperature   50°C/hr 10N
ISO 306
104
°C
Vicat Softening Temperature   50°C/hr 50N
ISO 306
96
°C
CLE
 ISO 11359
 9.3E-5
cm/cm/°C
Flammability
Standard
Value
Unit
Flame Rating   All Color 1.5mm
UL94
 HB

Flame Rating   All Color 3.0mm
UL94
 HB

⚠️The technical data sheet (TDS) of Chimei Polylac PA-747 ABS material, from Chimei corporation, if there are differences, please refer to the official website of Chimei.
