Borouge Borlink LS4201S XLPE

Application: high voltage cable

Melt flow rate: 0.922g/10min

Packing: 1100G/Bag

Process: Extrusion molding
Get Quotation

 Borouge Borlink LS4201S XLPE pellet Description

Borlink LS4201S is extrusion molding cross-linked polyethylene polymer (XLPE material) produced by Borouge. It has excellent insulation, electrical and ignition properties and is used in the production of high voltage cables.

Ultra-high voltage polyethylene borouge ls4201s

 ​​​​​​⚠️Note: the standard packaging of Borouge Borlink LS4201S XLPE is 1100kg/Box, if you need special packaging or samples, please contact us.

Borouge Borlink LS4201S XLPE pellet Advantage

  • High-voltage cable compound. Borouge LS4201S is a cross-linked polyethylene material specifically designed for the production of high-voltage AC cables. It offers excellent electrical properties and resistance to scorching. Additionally, this material has been certified to meet the American Electrical Industry Standard AEIC CS9, the Institute of Cable Engineers of America Standard ICEA S-108-720, the International Electrotechnical Commission Standards (medium and high voltage) IEC 60840 and (extra-high voltage) IEC 62067, as well as the European Harmonized Standard HD 632 S1. With its excellent electrical safety performance, it is commonly used in the production of high-voltage and extra-high-voltage cables.
  • Excellent electrical performance. Borlink LS4201S XLPE material is specifically designed for high-voltage cables with a maximum operating pressure of 230 kV/mm and a rated operating voltage of up to 230 kV. The volume resistance of Borlink LS4201S XLPE under 23℃ test environment is only 1E+16Ω.cm, and the dissipation factor under 50Hz test environment is only 0.0003, which effectively reduces the loss of electric energy during transmission and improves the transmission efficiency of high-voltage lines.
  • Good aging resistance. Borouge LS4201S has excellent thermosetting and aging resistance tests. The tensile properties under 135℃ 168hr test change is only 20%. The high-voltage cables made of it are suitable for long-term use, extending the service life of the cables.

Why choose Baiyou as Borouge Borlink LS4201S XLPE pellets supplier?

  • Leading cross-linkable polyethylene supplier (XLPE material) , 20+ years of experience in plastic product manufacturing and chemical raw material import and export
  • Fastest Arrival, with warehouses in multiple ports
  • 1,000+ types of resins are available, and we have cooperated with large petrochemical groups for 30+ years
  • Free Samples for production testing
  • Wholesale price, even a piece of goods is based on the wholesale price
 Key Attributes
Borouge Borlink LS4201S XLPE
Информация о продукте
Manufacturer
Borouge Pte Ltd Abu Dhabi
Part Marking Code
>XLPE material<
ColorNatural color
ProcessExtursion molding XLPE material
Specification
·AEIC CS8 ·AEIC CS9 ·ANSI/ICEA S-108-720 ·ANSI/ICEA S-93-639
·ANSI/ICEA S-94-649  ·ANSI/ICEA S-97-682 ·Cenelec HD 632 S1
·IEC 60840 ·IEC 62067 ·UL 1072
Features
·Crosslinkable ·Electrically insulating ·Good electrical properties
·Scorch resistance ·Short cycle time
Application
·High voltage cable applications ·Power cables
Physical properties
Standard
Value
Unit
Density base resin
ISO 11830.922
g/cm³
Melt index 190℃ 2.16kg base resinISO 11332g/10min
Moisture contentISO 15512200ppm
Max torqueISO 65022.9~3.8dNm
Mechanical behavior
Standard
Value
Unit
Tensile strength 250mm/min
ISO 52717
MPa
Elongation break 250mm/minISO 527450%
Thermal
Standard
Value
Unit
HDT set test 200℃ 0.2MPa elongation under load
IEC 60811-50775%
HDT set test 200℃ 0.2MPa permanernt elongation IEC 60811-5075%
Electrical properties
Standard
Value
Unit
Volume resistivity 23℃
IEC 626311E+16
Ω·cm
Dielectric constant 50Hz
IEC 602502.3
Disspation factor 50HzIEC 602500.0003

Aging
Standard
Value
Unit
Change in tensile properties 135℃ 168hr  IEC 60811-401 20
%
Extrusion moldingStandardValueUnit
Melt temperature125~135℃
⚠️The technical data sheet (TDS) of Borlink LS4201S crossed-link polyethylene resin (XLPE material) from Borouge Pte  Ltd, if there are differences, please refer to the official website of Borouge.
 Partners
We have established long-term relationships with 80+ well-known  companies around the world
  Warehouse And Shipping
20+ years' experience consultant with a supply chain of 1000+ plastic raw materials in China.
Quantity (tonnes)
1-100
100-300
>300
Lead time (days)
7-10
10-15
To be negotiated

References and Notes

  1. Borouge,"Borlink solution for wire & cable power cables", Borouge Pte Ltd , 24/06/2026
