Sabic Cycoloy C2950 PC/ABS

Features: High impact resistance; Heat resistance

Process: Injection molding PC/ABS material

Package: 25KG/Bag

Get Quotation

Sabic Cycoloy C2950 PC/ABS pellet Description

Cycoloy C2950 is a mixed resin pellets of impact resistant polycarbonate and Acrylonitrile Butadiene Styrene blend (PC+ABS material) produced by Saudi Basic Industries. It contains bromine-free and chlorine-free flame retardants, meets environmental protection requirements, can achieve UL94 V-0 flame retardancy, and has good mechanical properties and heat resistance.

Sabic Cycoloy C2950 PC/ABS pellet Advantage

Excellent impact resistance. As a polycarbonate and ABS mixed resin material, Cycoloy C2950 has the excellent high impact resistance of ABS material. The notched impact resistance under 23℃ test environment reaches 530J/m, and even under extreme low temperature environment of -30℃, it can still reach 160J/m, which is suitable for equipment with high impact performance requirements.
Good flame retardant performance. Cycoloy C2950 polycarbonate + ABS material contains high-performance flame retardant ingredients, which can achieve UL94 V-0 level flame retardant effect under the 1.5mm test standard. Moreover, Sabic PC/ABS C2950 uses halogen-free flame retardants that contain no bromine or chlorine and meet European and U.S. high-performance environmental requirements.
Good heat resistance. Cycoloy C2950 PC/ABS material has a heat deformation temperature of 90°C in a 3.2mm 1.8MPa test environment and a Vicat softening temperature of 112°C in a 50°C/hr 50N test environment. It is suitable for use in the production of heat dissipation systems with high high temperature performance requirements.

Why choose Baiyou as Sabic Cycoloy C2950 PC/ABS pellets supplier?

Leading polycarbonate + ABS resin pellets supplier (PC+ABS material) , 20+ years of experience in plastic product manufacturing and chemical raw material import and export
Fastest Arrival, with warehouses in multiple ports
1,000+ types of resins are available, and we have cooperated with large petrochemical groups for 30+ years
Free Samples for production testing
Wholesale price, even a piece of goods is based on the wholesale price

Key Attributes

Product information
Sabic Cycoloy C2950 PC/ABS
Manufacturer		Saudi basic industry corporation
Part Marking Code		>PC+ABS material<
Color		Natural color / Black
Process		Injection molding PC alloy material
Material Shape		·PC+ABS pellets
Flame retardant		·V-0 ·5VB
Material Attribute		·Bromine and chlorine free ·High heat resistance grade PC alloy ·UV resistance grade PC/ABS material
Specification		·UL
Features		·High impact
Additives		Flame retardant
Physical properties	Standard	Value	Unit
Density	ASTM D792	1.18	g/cm³
Density color	ASTM D792	1.22	g/cm³
Shrinkage flow 3.2mm	Internal method	0.4~0.6	%
Shrinkage xflow 3.2mm	Internal method	0.4~0.6	%
Water absorption 24hr	ASTM D570	0.1	%
Water absorption 23℃ equilibrium	ASTM D570	0.4	%
Melt index 260℃ 2.16kg	ASTM D1238	10	g/10min
Hardness	Standard	Value	Unit
Rockwell hardness R(Scale)	ASTM D785	123
Mechanical behavior	Standard	Value	Unit
Tensile strength yield 50mm/min Type Ⅰ	ASTM D638	62	MPa
Elongation break 50mm/min Type Ⅰ	ASTM D638	40	%
Flexural strength yield 2.6mm/min	ASTM D790	102	MPa
Flexural modulus 2.6mm/min	ASTM D790	2650	MPa
Izod notch impact 23℃	ASTM D256	543	J/m
Izod notch impact -30℃	ASTM D256	160	J/m
Instrumented impact 23℃ total energy	ASTM D3763	61	J
Instrumented impact -30℃ total energy	ASTM D3763	54	J
Thermal	Standard	Value	Unit
HDT unannealed 1.8MPa 3.2mm	ASTM D648	90	℃
HDT unannealed 0.45MPa 6.4mm	ASTM D648	104	℃
HDT unannealed 1.8MPa 6.4mm	ASTM D648	95	℃
Vicat softening temperature 50℃/hr 50N	ASTM D1525	112	℃
CLE Flow -30.0~30℃	ASTM D696	7.2E-5	cm/cm/℃
CLE xFlow -30.0~30℃	ASTM D696	7.2E-5	cm/cm/℃
Heat conductivity coefficient	ASTM C177	0.2	W/(m·℃)
Electrical properties	Standard	Value	Unit
Volume resistivity	ASTM D257	1E+17	Ω·cm
Surface resistivity	ASTM D257	1E+16	Ω
Dielectric strength 3.2mm in oil	ASTM D149	19.4	KV/mm
Dielectric constant 50/60Hz	ASTM D150	3
Dielectric constant 100Hz	ASTM D150	3
Dissipation factor 50/60Hz	ASTM D150	0.005
Dissipation factor 100Hz	ASTM D150	0.0049
Flammability	Standard	Value	Unit
Flame rating all color 1.5mm	UL94	V-0
Flame rating all color 2.0mm	UL94	V-0
Flame rating all color 2.5mm	UL94	V-0 5VB
Flame rating all color 3.0mm	UL94	V-0 5VB
Limiting oxygen index	ASTM D2863	32	%
Injection molding	Standard	Value	Unit
Dry temperature		80~90	℃
Dry time		3~4	hr
Water contenct control		≤0.04	%
Zone1 temperature		220~255	℃
Zone2 temperature		220~275	℃
Zone3 temperature		245~275	℃
Nozzle temperature		245~275	℃
Melt temperature		245~275	℃
Mould temperature		60~80	℃
Screw speed		40~70	rpm
Shot to cylinder size		30~80	%
Back pressure		0.3~0.7	MPa
Vent depth		0.038~0.076	mm
