BASF Ultramid A3K PA66

Material attribution: ·Heat stabilized grade

Process: Injection molding

Package: 25KG/Bag

Viscosity: Low viscosity

Get Quotation

BASF Ultramid A3K PA66 pellet Description

Ultramid A3K is low viscosity polyamide(PA66 material) produce by BASF SE, have a melt index of 120 cm³/10min (275°C 5k'g) and are suitable for injection molding. Containing heat stabilizers, lubricants, and release agents, they offer excellent heat and aging resistance and can be used in high-speed processing equipment, primarily in the production of cable connectors, bearings, gears, and high-pressure bearing parts.

BASF Ultramid A3K PA66 pellet Advantage

Heat-stable PA 66 material. BASF Ultramid A3K polyamide 66 contains the heat stabilizer, which has better high-temperature resistance than conventional polyamide materials. Its melting temperature reaches 260°C, and it can be used in a working environment of 200°C for a short period of time. It can work stably for more than 5,000 hours in a test environment of 118°C, and can be used in applications that are more sensitive to high temperature properties.
Excellent processing performance. BASF Ultramid A3K PA 66 has melt volume rate (MVR) of 120 cm³/10 min @ 275°C 5 kg, is high flow nylon. Its viscosity index under the ISO 307 test standard is 150 cm³/g, extremely low viscosity and high fluidity make it particularly well-suited for large-scale, high speed production equipment.

Why choose Baiyou as BASF Ultramid A3K PA66 pellets supplier?

Leading polyamide 66 resin pellets supplier (nylon 66 resin) , 20+ years of experience in plastic product manufacturing and chemical raw material import and export
Fastest Arrival, with warehouses in multiple ports
1,000+ types of resins are available, and we have cooperated with large petrochemical groups for 30+ years
Free Samples for production testing
Wholesale price, even a piece of goods is based on the wholesale price

Key Attributes

Product information
BASF Ultramid A3K PA66
Manufacturer		BASF corporation
Part Marking Code		>PA66 material<
Color		Natural color
Material Shape		·PA66 pellets
Process		Injection molding
Viscosity		Low viscosity
Flame retardant		V-2
Material Attribute		·Heat stabilized grade PA 66 material ·Injection grade PA 66 material
Features		·High flow ·Heat aging resistant ·Hot water resistant ·Good weather resistance ·High speed processability
Application		·Cable Connector ·Electrically insulating parts ·Terminals ·Bearing ·Gears ·Highly stressed parts
Additives		·Lubricant ·Heat stabilizer ·Mold release
Physical properties	Standard	Value		Unit
Density	ISO 1183	1.13		g/cm³
Shrinkage	Internal method	0.95		%
Shrinkage flow	ISO 294	1.50		%
Shrinkage xflow	ISO 294	1.80		%
Water absorption 23℃ saturation in water	ISO 62	8~9		%
Melt index 275℃ 5kg	ISO 1133	120		cm³/10min
Viscosity number 0.5% in 96% H2SO4	ISO 307	150		cm³/g
Mechanical behavior	Standard	Dry	Wet	Unit
Tensile modulus	ISO 527	3000	1100	MPa
Tensile strength yield 50mm/min	ISO 527	85	50	MPa
Elongation yield 50mm/min	ISO 527	4.5	20	%
Elongation break 50mm/min	ISO 527	30	50	%
Tensile creep modulus 1000hr 23℃ 0.5% strain	ISO 899		700	MPa
Flexural modulus	ISO 178	2900		MPa
Izod notch impact 23℃	ISO 180	5.5	NB	kJ/㎡
Izod notch impact -30℃	ISO 180	6		kJ/㎡
Charpy notch impact 23℃ 1eA	ISO 179	5	20	kJ/㎡
Charpy notch impact -30℃ 1eA	ISO 179	4		kJ/㎡
Charpy un-notch impact 23℃	ISO 179	NB	NB	kJ/㎡
Thermal	Standard	Value		Unit
HDT 1.8MPa	ISO 75	75		℃
HDT 0.45MPa	ISO 75	220		℃
Melting temperature DSC	ISO 11357	260		℃
CLE Flow 23℃~80℃	ISO 11359	9.8E-5		m/m/K
CLE xFlow 23℃~80℃	ISO 11359	9.7E-5		m/m/K
Heat conductivity coefficient	DIN 52612	0.33		W/(m·K)
Specific heat	Internal method	1700		J/(kg·K)
Service temperature short time	Internal method	200		℃
Service temperature 5000hr	IEC 60216	118		℃
Service temperature 20000hr	IEC 60216	101		℃
Electrical properties	Standard	Dry	Wet	Unit
Volume resistivity	IEC 62631	1E+13	1E10D	Ω·cm
Surface resistivity	IEC 62631-3-2		1E10	Ω
Dielectric contant 1MHz	IEC 62631-2-1	3.2	5
Dielectric facotr 1MHz	IEC 62631-2-1	0.025	0.2
CTI solution A	IEC 60112		600	V
Flammability	Standard	Value		Unit
Flame rating 0.4mm	UL94	V-2
