victrex 450ca30 peek pellet

Victrex 450CA30 PEEK | CA30 reinforced

Features: Ultra stiffness; Wear resistance

Process: Injection Molding/ Extrusion molding

Packing: 25KG/Bag
Get Quotation

 Victrex 450CA PEEK pellet Description

Victrex 450CA30 polyetheretherketone material, medium viscosity, high fluidity, suitable for injection molding and extrusion molding processing, contains 30% carbon fiber reinforcement, has ultra-high strength and rigidity, extremely low shrinkage, and the finished product is extremely stable

peek with carbon fiber

⚠️Victrex 450CA30 PEEK has two textures, powder packaging 20kg/bag, granular packaging 35kg/bag.
⚠️Victrex 450CA30 PEEK particles are black due to the carbon fiber content, as shown in the left picture. The actual color may vary due to lighting. For more details, please contact us via WhatsApp

WhatsApp:+86 15837933829

Victrex 450CA30 PEEK pellet Advantage

  • Ultra-high strength and rigidity resin material. Compared with unreinforced polyetheretherketone materials, Victrex 450CA30 contains 30% carbon fiber, which has improved strength and rigidity. The tensile modulus under the 23°C test environment reaches 28GPa, the bending modulus reaches 24GPa, and the compressive strength reaches 320MPa. The mechanical strength is extremely superior and has excellent advantages in high-end applications and demanding applications.
  • Extremely low shrinkage. Compared with conventional PEEK materials, the shrinkage of Victrex 450CA30 is only 0.3% at 23°C and 0.45% at 100°C, which is much lower than the same grade of polyetheretherketone materials, making it widely used in precision and high-standard application fields.
  • Excellent wear resistance. Victrex 450CA30 contains 30% carbon fiber, which improves the lubricity of the finished product and is suitable for applications with high lubricity requirements.
  • High food contact safety performance. Victrex 450CA30 PEEK has passed FDA-related tests and can be used in food contact applications and medical care applications

Why choose Baiyou as Victrex 450CA30 PEEK pellets supplier?

  • Leading Polyetheretherketone supplier (PEEK resin) , 20+ years of experience in plastic product manufacturing and chemical raw material import and export
  • Fastest Arrival, with warehouses in multiple ports
  • 1,000+ types of resins are available, and we have cooperated with large petrochemical groups for 30+ years
  • Free Samples for production testing
  • Wholesale price, even a piece of goods is based on the wholesale price
 Key Attributes
Victrex 450CA30 PEEK
Product information
Manufacturer
Victrex plc
Part Marking Code
>PEEK material<
Color·Black
Material Shape
·PEEK pellets ·PEEK powder
Process
Injection molding PEEK material
Extrusion molding PEEK material
Flame retardantV-1 V-0
Material Attribute
·Food contact grade  ·30% carbon fiber reinforced
·Flame retardant ·Wear resistance
Features
·Semi crystalline ·High stiffness ·High strength ·Low friction
·Chemical resistance
Physical property
Standard
Value
Unit
Density
ISO 1183
1.40
g/cm³
Shrinkage flow 395℃ mold temperature:200℃
ISO 294
0.1
%
Shrinkage xflow 395 mold temperature:200℃
ISO 294
0.5
%
Water absorption 23℃ saturation in waterISO 620.1%
Water absorption 100℃ saturation in waterISO 620.45%
Melt Viscosity 400℃
ISO 11443
675Pa·s
Spiral flow 395℃ temperature:200℃ 1.0mmInternal method75mm
Spiral flow 395℃ temperature:200℃ 3.0mmInternal method330mm
Hardness
Standard
Value
Unit
Shore hardness D 23℃ISO 86887.5
Mechanical behavior
Standard
Value
Unit
Tensile modulus 23℃
ISO 527
28
GPa
Tensile strength break 23℃
ISO 527
265
MPa
Tensile strength break 125℃ISO 527160MPa
Tensile strength break 175℃ISO 52785MPa
Tensile strength break 275℃ISO 52750MPa
Elongation break 23℃
ISO 527
1.7
%
Flexural strength 23℃ISO 178380MPa
Flexural strength 125℃ISO 178275MPa
Flexural strength 175℃ISO 178130MPa
Flexural strength 275℃ISO 17865MPa
Flexural modulus 23℃ISO 17824GPa
Izod notch impact 23℃ISO 18010.5kJ/㎡
Izod un-notch impact 23℃ISO 18050kJ/㎡
Charpy Notch impact 23℃
ISO 179
7.0
kJ/㎡
Charpy un-Notch impact 23℃
ISO 179
45
kJ/㎡
Compressive strength 23℃
ISO 604
320MPa
Compressive strength 120℃
ISO 604
200MPa
Compressive strength 200℃ISO 60470MPa
Thermal
Standard
Value
Unit
HDT 1.8MPa
ISO 75
336
℃
Melting temperature
ISO 11357
343
℃
Glass transition temperature onsetISO 11357143℃
Glass transition temperature midsetISO 11357150℃
CLE Flow below Tg
ISO 11359
5E+0μm/m/℃
CLE below TgISO 113594E+1μm/m/℃
CLE Flow above TgISO 113596E+0μm/m/℃
CLE above TgISO 113591E+2μm/m/℃
Heat conductivity coefficient 23℃ flowISO 220072.0W/(m·K)
Heat conductivity coefficient 23℃ISO 220070.95W/(m·K)
Electrical properties
Standard
Value
Unit
Volume resistivity 23℃ 1V
ASTM D44961E5
Ω·cm
Flammability
Standard
Value
Unit
Flame rating Black 0.41mm
UL94
V-1

Flame rating Black 0.75mmUL94V-1
Flame rating Black 1.5mmUL94V-0
Flame rating Black 3.0mm
UL94
V-0

GWFI 2mm
IEC 60695
960
℃
⚠️ The technical data sheet of Victrex 450CA30 PEEK with 30% carbon fiber, from Victrex plc, if there are difference, please refer to the official website of Victrex.
